| 7120009 - | KVFU 10 A UL |

Generating diagrams...
Generating diagrams...
|
KVFU 10 A UL 7120009 |
||
|---|---|---|
| Parameter | Value | Unit |
| Voltage | 115 | V |
| Phase | 1 | ~ |
| Frequency | 60 | Hz |
| Power | 138 | W |
| Current | 1.21 | A |
| Speed | 2545 | r.p.m. |
| Max. temperature of transported air | 75 | °C |
| Max. temperature of transported air when speed controlled | 75 | °C |
| Sound pressure level at 3 m | 66 | dB(A) |
| Weight | 4.4 | kg |
| Enclosure class | 44 | IP |
| Insulation class, motor | F | |
| Capacitor | 10 | µF |
| Duct connection | 250 | mm |
| Max. flow @ 0Pa | 284 | l/s |
| Max. pressure | 552 | Pa |
| Voltage range | 110-120 | V |
