IFK 140 B1 AC left Updated: 2026-01-22

7800045 - IFK 140 B1 AC-v2 Left

  • Insulated duct fan with circular connections.
  • Designed as a cooker exhaust fan and can be connected to a cooker hood.
  • Equipped with 30 mm fire retardant insulation.
  • Handles high pressures yet offer low sound levels.
  • It features 2 inlets and 1 outlet.
  • Impeller with forward curved blades.
  • The external rotor motor has maintenance-free sealed ball-bearings.
  • Integrated motor protection.
  • Junction box has enclosure class IP 54.
  • For speed control a transformer or electronic speed controller can be connected.
  • The housing is manufactured from galvanized sheet steel.
  • Duct connections are equipped with rubber seals.
  • Swing-out design to simplify maintenance and cleaning.
  • The fan is intended to be installed in a duct system.
