7340119 - |
TKV 300 C1 EC-v1 Black Archived product |
7340121 - | TKV 300 C1 EC-v1 Brick red |
TKV 300 C1 EC-v1 Black 7340119 Archived product |
TKV 300 C1 EC-v1 Brick red 7340121 |
|||
---|---|---|---|---|
Parameter | Value | Unit | Value | Unit |
Voltage | 230 | V | 230 | V |
Phase | 1 | ~ | 1 | ~ |
Frequency | 50/60 | Hz | 50/60 | Hz |
Power | 99 | W | 99 | W |
Current | 0.84 | A | 0.84 | A |
Speed | 3530 | r.p.m. | 3530 | r.p.m. |
Max. temperature of transported air | 60 | °C | 60 | °C |
Max. temperature of transported air when speed controlled | 60 | °C | 60 | °C |
Sound pressure level at 3 m | 67 | dB(A) | 67 | dB(A) |
Weight | 5.6 | kg | 5.6 | kg |
Enclosure class | 54 | IP | 54 | IP |
Insulation class, motor | F | F | ||
Capacitor | - | µF | - | µF |
Duct connection | 300x300 | mm | 300x300 | mm |
Max. flow @ 0Pa | 189 | l/s | 189 | l/s |
Max. pressure | 619 | Pa | 619 | Pa |
Voltage range | 220-240 | V | 220-240 | V |
Parameter | Value | Unit |
---|---|---|
(a) Manufacturer | Östberg | - |
(b) Model code | TKV 300 C1 EC-v1 | - |
(c) Declared type | NRVU / UVU | - |
(d) Type of drive | Variable speed drive | - |
(e) Type of HRS | N/A | - |
(f) Thermal efficiency | N/A | % |
(g) Nominal flow rate | 0.113 | m3/s |
(h) Effective power input | 0.099 | kW |
(i) SFP int | N/A | W/(m3/s) |
(j) Face velocity | 3.6 | m/s |
(k) Nominal external pressure | 371 | Pa |
(l) Internal pressure drop | N/A | Pa |
(n) Static efficiency | 48.2 | % |
(o) External (and internal) leakage rate | N/A (N/A) | % |
(p) Filter classification | N/A | - |
(q) Visual filter warning | N/A | - |
(r) Sound power level | 74 | dB LwA |
(s) Disassembly instructions | www.ostberg.com | - |
